American Style Energy Storage All-in-One Machine
The energy storage converter and stepup integrated machine optimizes and integrates the medium-voltage high-power energy storage converter, switch cabinet and step-up transformer. It owns higher power of single equipment, simple application, flexible installation site selection, convenient operation and maintenance characteristics. The system can be connected with the power grid at the high voltage of 10kV/35kV, which can reduce the complex high-voltage system design work, shorten the system design period and decrease the system design cost.
Features
The equipment contains oil-type transformer, PCS high and low voltage switch gear and so on. Its voltage level ranges from 6kV to 35kV and capacity from 0.5MW to 3.75MW.
-
Simple Installation
It is integrated with energy storage PCS+step-up transformer. It owns simple installation, operation and maintenance.
-
Multi-Level Protection
Large DC working voltage range, up to 1500V full load operation. Supports battery charge and discharge, cooperate with EMS and BMS to realize multi-level protection of the system.
-
Quick Power System
High adaptability for fast power dispatch, off-grid and black start grid.
-
Adaptable
Own PO, VF and SVG functions, can support high voltage and low voltage crossing.
Superior Performance: It is designed and integrated with reverse and change functions, can be delivered conveniently. It is installed and maintained with local controller, which can realize the unified control, dispatch and online fault diagnosis.
Efficient: The integrated and efficient three-level topology energy storage converter is applied. Based on its maximum efficiency, 99% forced air cooling and 110% long-term overload capacity and be realized, and the capacity will not reduce at 122ºF environment.
High Power: It can be used in various energy storage application situations such as peak decreasing and valley increasing, frequency modulation and peak adjustment, assisting new energy grid connection. It owns PO, VF, VSG, SVG functions, and can support off-grid operation and black start.
